2M252 is water-cooled 2450MHz continuous wave magnetron designed for industrial heating applications. It has packaged Magnet & probe output which can deliver the output upto 3000W with matched load. It requires the continuous water supply to maintain the anode temperature of the magnetron. It is available in following configurations. mounting, air flow & connector in same directions. mounting & air flow are not in the direction of the connector.   The magnetron is recommended to be mounted in vertical position. Its antenna should always be in either upward or downward direction.

2M256 is a 2450 MHz continuous wave magnetron designed for industrial heating applications. It has packaged Magnet & can deliver the output upto 2KW with matched load. During operation, it require the continuous water supply to maintain the temperature of the magnetron. It has tungsten filament which is very brittle material therefore it is advisable to avoid any mechanical shock to the magnetron. The magnetron should be mounted in vertical position. Its antenna should always be in either upward or downward direction.
